Humans love stimulants! We have always enjoyed zapping ourselves and each other, just a little bit, or even quite a lot.123 For many decades, by far the most popular (and tame) form of electrotherapy or neuromodulation4 has been transcutaneous electrical nerve stimulation (TENS). Other kinds of electrical stimulation are also interesting, and more promising, like deeper stimulation — zapping the brain and spinal cord. This is an overview of all forms of neuromodulation with a strong focus on TENS for pain.
TENS therapy has been a staple in physical therapy and chronic pain clinics for decades. There are many types of consumer TENS machine on the market. It has a huge following of believers, both providers and customers.
I do think we are heading into an era of using … both electrical & magnetic stimulation as a therapeutic tool.
Dr. Steven Novella, Nerve Stimulation for Relaxation
But people will believe anything! (You may have noticed this.) Much like ultrasound, this old-school techy therapy isn’t all it’s cracked up to be: the effectiveness of TENS “is based on individual experience rather than scientific evidence,” which seems odd for such a popular therapy. But it’s probably not entirely useless — interesting sensations, presented in the right way to patients, can always get something done (sensation-enhanced placebo).
What does “TENS” stand for? Transcutaneous electrical nerve stimulation. “Trans” means across or through, and “cutaneous” means affecting skin, so TENS refers to the stimulation of electricity passing through skin between electrodes.
What does a TENS unit do? Why would anyone want to use one?
If you stick a couple of electrodes on your skin and pump an electric current through your tissues, you will tickle your nerves and stimulate interesting sensations and/or some mild muscle contractions, which may temporarily drown out pain or “distract” us from it. More about the biology below.
You can fiddle with various dials for different flavours of TENS. For instance, you can boost the intensity and frequency to get more muscle contraction.5 With a powerful enough TENS machine (“These go to eleven.”), it is possible to “taze yourself.”
And so it’s possible that just the right setting makes all the difference, just like with phasers. This makes the topic endlessly debatable, even though it’s obvious that typical TENS doesn’t work many miracles. In fact, it probably mostly doesn’t work much better for most pain than an aspirin, and it’s not much good for anything else except maybe some relaxation or gently exercising muscles in rehab.
And central stimulation? Tickling the brain and spinal cord with electricity
And then there’s central stimulation — stimulation of the spinal cord or brain — the other major kind of neuromodulation. It’s possible to do this non-invasively, but probably not possible to do it well (more below). To get it right, you’ve probably got to get right in there with an actual implant: more invasive, profound, and dangerous, but also more impressive results for more serious problems like Parkinson’s diseases, major depression, and severe chronic pain. This approach has roots in electroconvulsive therapy — “electroshock” therapy back in the day — but the modern era of electrical therapy began when deep brain stimulation was introduced in 1987, and it’s been steadily improving since then, mostly thanks to better surgical techniques for implants.
Now, if only we knew how it worked! No one actually does, and there are several possibilities, like vagus nerve stimulation to control inflammation for rheumatoid arthritis — extremely interesting, but far from an established effect.6 That’s an advanced topic, beyond the scope of this article, but it’s a topic worth watching over the next decade.
As brain-machine interfaces continue to improve, we are likely to see some real progress. Consider a 2021 study that demonstrated substantial pain relief using a smart implant in rat brains.7 Cool stuff! But it’s about as close to TENS as rocket science is to paper airplanes.
Maybe if you zap this, it will be happier? Kind of a strange hypothesis when you think about it. Why would brains respond well to electromagnetic forces? I mean, hey, anything’s possible, but it’s not like there’s any obvious reason to think so.
Non-invasive brain stimulation techniques for chronic pain
Why invade when you can just surround? Spoiler: because it doesn’t work as well. Non-invasive brain-stim aims to stimulate brain tissue from the outside by various means,8 but all of them are “transcranial” stimulation with something, mostly magnetism and direct current — just like TENS, but with the electrodes attached to your head.
To date, there isn’t much reason to think that any of them are actually effective for pain. A 2015 British Medical Journal editorial ruled “not recommended; early promise is fading fast as trial methods improve” (commenting on a rare good quality trial9). In 2018,the Cochrane Database of Systematic Reviews just declared the evidence to be pathetic — not enough good studies like Luedtke et al. But the evidence so far is already following a classic pattern: slightly promising results from sloppy studies, discouraging results from the better ones that follow. The null hypothesis will probably rule the day, as it usually does.10
TENS costs and safety
TENS machines can be had for around $100, or even less for a few bargain models, but it is possible to spend several hundred on more power, options, or trendiness.
Although there is a tiny risk of mild shock from faulty devices, consumer TENS units are just too weak to be dangerous, and the risk of too much juice in a medical setting is extremely low.11 Overzealous self-treatment might cause some skin irritation around the electrodes.
Could TENS cause pain or other neurological symptoms?
Other than direct injury, it’s conceivable that TENS could backfire and actually cause pain instead of relieving it. I’ve wondered about this, and went looking for evidence of it — and found none. If it occurs, it’s rare and relatively minor.
But I still think it’s plausible. Any unusual stimulus can potentially be a trigger for the symptoms of certain diseases (headache triggers like chocolate and wine are a classic example). A TENS backfire would not involve any harm to the nerves themselves, just a sensory over-reaction.12 Many cases of backfiring might not quite reach the level of pain. For instance, mild numbness, tingling, and other paresthesias are also possible. These are extremely common symptoms in people even when we aren’t pumping electric current through our flesh, and they usually are completely harmless and temporary, triggered by a variety of minor physiological and psychological circumstances. The strange sensations of TENS, for some patients, might trigger an “attack” of tingling or numbness.
The best defense against such reactions to TENS — or any weird stimulus — is mental confidence and optimism.
Do TENS machines work? Is there any scientific evidence that TENS can treat pain?
People tend to ask “how does TENS unit work?” before asking the much more important question: “do tens machines work?” There is some evidence that TENS helps pain, but it’s a bit sketchy. Superficial TENS is well-studied as these things go: there have been enough studies that there are several reviews of the studies. However, a lot of the reviews were inconclusive, because they’re reviewing a lot of weak data. Par for the course in musculoskeletal medicine, unfortunately: garbage in, garbage out.
|Milne 200113||negative review of 5 trials of TENS for chronic low back pain|
|Johnson 200714||positive review of 38 trials of TENS for chronic musculoskeletal pain, “effective”|
|Nnoaham 200815||inconclusive review of 25 studies of TENS for chronic pain|
|Khadilkar 200816||inconclusive review of 4 trials of TENS for chronic low back pain|
|Walsh 200917||inconclusive review of 12 trials of TENS for acute pain|
|Hurlow 201218||inconclusive review of 3 trials of TENS for cancer pain|
|Vance 201419||mixed review: “it’s complicated” but promising|
|Chen 201520||negative review of 18 trials for knee osteoarthritis|
|Desmeules 201621||inconclusive, discouraging review of 6 trials for rotator cuff tendinopathy|
|Li 201722||barely positive meta-analysis of 5 weak trials for pain after knee replacement|
|Salazar 201723||barely positive meta-analysis of 9 weak trials of stim for fibromyalgia|
That doesn’t look great: five disappointingly non-positive,24 two spankings for back pain and osteoarthritis, two that damn TENS with faint praise, and just the one clearly positive review out of eleven (which is also one of the oldest and perhaps the least picky).25
But that 2014 one … “it’s complicated” is an understatement! Vance et al is a more formal and thorough version of what I’m doing here.26 Although it’s dense reading, they do a good job of putting it all in perspective, and point out several reasons why the evidence reviewed here is probably not the whole story, and why they remain optimistic that the right TENS (intensity, duration) for the right kind of pain could still be good medicine.
That kind of talk is often a red flag,27 especially when the same researchers have also argued that there is probably a “strong placebo component” with TENS.28 But sometimes it’s fair, and this might be one of those times. Maybe science hasn’t asked the right questions yet. Despite the messy evidence, Vance et al. believe that “both high-frequency and low-frequency TENS have been shown to provide analgesia specifically when applied at a strong, non-painful intensity.”
My official position for now is that it probably works well enough for some patients to be worth trying if you’re desperate … but keep your expectations low. There are solid reasons to doubt that TENS can work well.
If TENS works, how does it work? Digging deeper into the biology
What does a tens unit actually do to treat pain? The mechanism cited most often is the counterstimulation effect: pre-empting pain with other sensations. This effect is real but minor, and particularly unlikely to be helpful with severe or chronic pain.
The obligatory, canonical example is that animals instinctively rub on or near acute minor injuries. We self-treat with counterstimulation all the time, and sometimes we even counterirritate ourselves (like pounding on your thigh after a toe stub).
This is often informally explained as “distracting” us from pain — we’re basically flooding sensory pathways with competing sensations, and (weirdly) the nervous system gives priority to tactile sensation over noxious stimuli. This is the phenomenon of counterstimulation, which is based on some “simple” neurology, sensory bottlenecks in the spinal cord (“gate control theory”). It’s not a high-level, top-down phenomenon. It exploits a limitation and quirk of our wiring. The effect is real, but generally minor and transient. Citing it as a mechanism for TENS is pretty weak sauce (but often done, because it sounds science-y).
But what if it wasn’t always so minor and transient? But what if there was a fancier, better version of the same thing?
Fancy counterstimulation: novel sensory input descending modulation
In this section, I will give TENS the benefit of the doubt and spitball optimistically about how a bit of tingling might deliver something a little more robust more than a trivial counterstimulation effect. This hypothesis can be applied to any unusual sensation, and may in fact explain why many kinds of therapy are mildly effective. But even if it explains why it works better than simple counterstimulation, it probably also explains its modest limits.
This is basically about amusing and calming the brain with interesting, non-threatening sensations, resulting in some “descending modulation”: the brain turning the alarm volume down.
All pain is ultimately generated by an overprotective brain that likes to sound the alarm too loudly, too often, regardless of what’s actually going on in tissues. This means that many kinds of chronic pain are partially and briefly treatable with tricks and hacks and virtually any novel stimulation.29 Unfortunately, your brain is stubborn and it’s hard to convince it to shut up about pain completely — short of knocking it out, which is why anaesthesia is the only truly effective analgesia.
The brain decides what hurts based on many sources of information. TENS messes with that system. It blasts the nervous system with static, sensory white noise. By stimulating nerves in this strange way, TENS doses the brain with unusual sensory information, which either “drowns out” information about tissue damage, and/or simply distracts the brain and forces re-evaluation. If it happened without warning or explanation, it would probably be scary and make the pain worse. But pay good money for it and call it “therapy,” and it can be reassuring instead. Context is everything!
But TENS cannot actually stop the brain from doing its job! Unless you turned it up enough to actually disable your brain.30 If your brain thinks you need to be in pain, the alarm is going to start going off again sooner or later — maybe right after the TENS is turned off.
Basically what all of this means is that TENS might deliver what I call sensation-enhanced placebo. Placebo is “relief from belief,” and the belief can be (greatly) enhanced by novel sensations. Every placebo involves some degree of fundamentally dishonest exaggeration to make the patient believe that it’s better than it actually is. Treatments that produce unusual sensations have an advantage, because the unusual sensation makes the treatment seem much more legitimate and special. If you take this far enough, it seems less like a placebo and more like we’re doing something therapeutic to the body. But if it boils down to convincing the patient’s brain to dial down the pain, it’s still a placebo at heart — just a fancy one.
TENS for muscle knots
The most common kind of musculoskeletal pain that doesn’t have an obvious cause is probably the “muscle knot” or “trigger point” — a patch of sensitive soft tissue, which is still mysterious after decades of sparring with it scientifically. All we really know for sure is that they feel like aching muscle, and they’ve inspired a lot of theories and half-baked cures.31 Trigger points are as likely a target for TENS as anything else, and it’s safe and cheap enough to be worth trying in difficult cases.
A 1997 study of TENS specifically for treating these little monsters found positive results.32 Yes, you read that right: positive! Some good news for once. Of course, the “just one small study” disclaimer applies in a big way: one study never proves anything, and I think this is the only one of its kind. But it was a reasonably good experiment, and the results were promising.
They compared nerve stimulation, muscle stimulation, and a placebo for 60 patients with knots in their shoulders (trapezius). They measured pain, pressure sensitivity, and range of motion (neck sidebend) before and after treatment. Muscle stimulation improved range of motion (but not pain/sensitivity), and nerve stimulation improved pain/sensitivity (but not range).33 The authors concluded:
ENS is more effective for immediate relief of myofascial trigger point pain than EMS, and EMS has a better effect on immediate release of muscle tightness than ENS.
The effects were statistically significant, but not clinically dramatic enough for them to boast about. But there’s enough here that I really wish someone would try the experiment again with more people. Maybe someday!
Electrical muscle stimulation: EMS vs. ENS
Just as electrical stimulation can be shallow or deep, there’s also electrical stimulation of muscle rather than nerves: electrical muscle stimulation (EMS), or neuromuscular electrical stimulation (NMES). (They are all “transcutaneous,” but for some reason T-for-transcutaneous is usually only use when referring to nerve stim. There is no “TEMS.”)
The right electrode placement and settings will stimulate muscles more than nerves, forcing them to contract. And so EMS may be a useful trick for exercising muscles, slightly useful in rehabilitation and, perhaps, performance enhancement. EMS feels like doing light isometric muscle contraction exercises — that is, clenching muscles without moving joints.
Or you could just do isometric muscle contractions, of course.
Forcing the issue with electrodes may be more about novelty than utility. But why not? I like gadgets as much as the next guy (or more, my office is pretty thick with them). It might just be fun to use EMS.
What EMS might be good for
Whereas traditional TENS is primarily used to try to treat pain, EMS is mostly meant for athletic training and performance enhancement — which is speculative and somewhat optimistic but not necessarily totally out to lunch — and rehabilitative scenarios like preventing muscles from atrophying from disuse after trauma, which makes sense and seems to work at least a little.34
Do beware of using it on actual muscle injuries though (muscle strains). Electrically stimulating a damaged muscle to contract is very “What could possibly go wrong?” EMS isn’t brutal. It’s unlikely to be a problem. But still! Be careful, for pity’s sake.
Many readers are curious to know specifically if EMS can help them maintain fitness when otherwise resting or incapacitated from an injury, especially stubborn overuse injuries like runner’s knee or plantar fasciitis that may require a period of substantial resting before a tedious phase of “baby steps” rehabilitative exercise. That’s exactly what EMS is good for, in theory, but in practice the benefits are probably trivial. For instance, in one study it didn’t help people with moderate knee osteoarthritis.35
Arthrogenic muscle inhibition (AMI)
AMI is the weird semi-paralysis of muscle in response to injury, most often seen in the quads after knee injuries.36 It’s a protective mechanism that gets out of hand (which is, interestingly, exactly analogous to a lot of chronic pain).37
AMI seems like the kind of thing that EMS was made for. If you can’t zap dysfunctionally inhibited muscles back into action, what can you zap? One blogger claims that EMS is “an integral part of the rehabilitation pre and post ACLR.” O rly? Sadly, the reference she gave doesn’t actually support that38 — and that’s how these things end up sounding better than they are. Other studies do lean that way,39 but not all.40 If my quads were still emaciated months after an injury, I would certainly try EMS — but not until the AMI was clearly dysfunctional, rather than just routine wisdom-of-the-body stuff after an injury.
Even if EMS works a little, in most cases the effect is nothing you couldn’t get just as well or more so with isometrics over time, and much more conveniently and cheaply to boot. Half-arsed optimization of muscle conditioning in the early stages of rehab should not be a high priority for most people. The exceptions might be people who are more profoundly injured, have unusually persistent AMI, or have specialized training needs due to a progressive disease.
And there is that entertainment value! EMS is kinda neat to make your muscles vibrate.
More TENS claims: relaxation
Are you tense? Try some TENS! It’s probably at least a little bit relaxing, and anything truly relaxing is at least a little bit good for pain — but only a little bit. Relaxation is weak medicine, as anyone with chronic pain can tell you. TENS has always been seen as a trivially relaxing therapy, just like a vibrating massager is: it literally vibrates muscle, as well as producing buzzing and tingling sensations that are quite similar to the feeling of vibration. Actually, I suspect that vibration is a major reason why TENS is a thing.
These days, the relaxation claims are fancier. (Almost everything about TENS is fancier these days.41)
What if TENS could stimulate specific nerves in a specific way, to create a more profound effect? That’s what the Thync (pictured at the top of the article) is supposedly doing, and either relaxing or invigorating depending on what mode it’s in: “Thync uses neurosignaling to activate42 specific cranial and peripheral nerves … signalling brain regions to change the way you feel.” Unsurprisingly, skeptical neurologist Dr. Steven Novella’s late 2015 review of the Thync is discouraging.43 For me, $200 is not an outrageous price for a little interesting experimenting on myself, and I’ll probably try it for fun. But I’m keeping my expectations low. If I’m really serious about getting into a deeply relaxed state, I suspect practicing meditation would offer better bang for buck. Or even just a hot bath.
And how about the more traditional approach? For instance, how about using TENS to reduce jaw clenching in a patient with temporomandibular joint syndrome? It’s a good example to consider, because it’s a classic example of the combination of muscle clenching and pain. If TENS is relaxing, it should be able to help this problem. The evidence is very limited and mixed. A little 2001 study is the only reasonably well-designed test I could find. It compared TENS to biofeedback in 20 patients. Unfortunately, neither method had any effect: those jaw muscles kept right on clenching, as measured by EMG.44 That is a bummer.
And I’d still try it if I had temporomandibular joint syndrome. The right settings could make the difference!
“Just the right settings”
With any therapy that depends on physics and technology, there’s always a handy justification for optimism: you just need the right combination of frequency, amplitude, intensity, [insert exotic parameter here]. There’s always someone who claims that their patented device is the only one that gets it right. No matter how poor the evidence for conventional approaches is, the gadget marketers can always say, “Yes, obviously ordinary TENS will fail — you need our special sauce.”
It’s a great strategy because it’s impossible to definitively contradict.45 But the longer people try to find “just the right settings” without ever proving that such a combination does exist, the more it turns into special pleading — claiming to be a “special” case, an exception to the trend.46
This is a pitch perfect example of TENS special pleading based on this trope, from the marketing for “Action Potential Simulation Therapy”:
The APS therapy wave form is an [sic] direct copy of an action potential, the body’s own electrical signalling system, which is what makes it unique. We are often asked if this is the same as TENS. The answer is no. To compare, a TENS machine uses a current of a thousandth of an amp, or 0.001, to creat [sic] a tingle that distracts from pain. APS Therapy uses a current of 0.00 0001, or a millionth of an amp., to get the cells firing more effectively, to address the underlying cause of pain, amongst other things.
The body does not have any one clear type of “action potentials” to replicate, even if doing so is what actually matters. Electrical engineering contains a bewildering diversity that takes serious expertise to even begin to master, but biology is dramatically more complex! But this company claims that they make a “direct copy of an action potential,” as it could ever be one replicable thing, and as if we know that would be an effective strategy even if it was possible. Classic therapy babble.
MOAR! Whole body TENS, anyone? Old timey galvanic baths
As if there aren’t enough TENS options with a few electrodes and several dials, you can — if you’re eccentric — run current through your whole body in an electric bath. This current would hopefully only be direct (galvanic) current for safety.47 But for the same reason it’s safer, direct current is also less stimulating: it causes a smooth, sustained muscle contraction, whereas the alternating current of TENS makes your muscles vibrate. Sounds relaxing, eh? Spasm baths!
Do not try at home.
Galvanic baths are mostly an old-timey thing you would have a hard time trying even if you wanted to, but they are an entertaining example of electric therapy.
“What is so strange about a galvanic bath?” one reader asked me. I suppose it’s not quite as outrageous as it looks, but it does reek of what could possibly go wrong? And, medically speaking, it’s quite a bit farther out in left field than TENS, quite unlikely to be good for anything. There’s no known or plausible therapeutic mechanism other than “it feels kinda funny.”
If nothing else, galvanic bathing was doomed to extinction by economics: the high cost of the infrastructure and equipment to deliver such treatments is way out of proportion to the slim hope of any significant benefit. Plus, can you imagine the lawsuits it would generate today?
TENS has a fascinating cousin: pulsed electromagnetic field therapy
Pulsed electromagnetic field therapy (PEMF) is clearly kin to TENS, a member of the electrotherapy family. It’s also related to simple (“static”) magnet therapy, which is mostly far more snake oily48 and less plausible than electrical stimulation.49
But this is a different beast, it’s very own thing. It’s more exotic, with a more mysterious mechanism of action. PEMF is hypothesized to directly stimulate cellular repair, and not for nothing: it actually seems to do that, and the effect is almost magical, speeding up bone fracture healing, and even restoring it in cases where healing has failed completely.50
Amazingly (and completely unexpectedly for me), the scientific reviews of PEMF used for this purpose are unstintingly positive.5152 When does this happen in musculoskeletal medicine? Never, that’s when. Which is suspicious in itself.
If PEMF can help fractures heal, it’s certainly reasonable to wonder what else it can do. But only recently have PEMF devices gotten small and cheap enough for consumers and less critical medical applications. Can they work on more ordinary problems? Like arthritis? Something TENS can only treat effectively with just the right settings and variables, that no one can seem to confirm?
Some trials of PEMF for these purposes are unambiguously positive.53 Even though there’s some hope for TENS with just the right settings, the best evidence is only lukewarm, and confirmation awaits better trials of just the right sort of TENS for the right sort of patients. Meanwhile, PEMF is in that fragile “promising” stage that few therapies actually emerge from unscathed. A cynic would wisely predict that higher quality studies are going to be disappointing.
TENS compared to nerve conduction testing
These two things seem similar: in both cases, electrodes are applied to the skin, and current is passed through the tissues between them. But while TENS is tame and (hopefully) therapeutic, nerve conduction testing is diagnostic and rather unpleasant — higher voltage and amperage makes it feel much more like an series of unpleasant electrical shocks.
The purpose of a nerve conduction test is to determine the health of peripheral nerves by measuring how quickly they conduct electricity. Several pathologies interfere with conduction in distinctive ways. To get the speed, mild electric shocks are applied at very specific locations so that the electricity will mostly zap its way down a specific peripheral nerve axon, to an electrode several inches away.
This causes some discomfort at the location of the shock, and also stimulates the nerve quite strongly. Shocking of motor and sensory nerves causes muscles to twitch and sensations to blare. It feels pretty much like what you’d expect: zappy!
